Performance Characteristics
1: High-quality aluminum lamp body, excellent thermal conductivity, rapid heat dissipation to ensure the normal constant temperature of the lamp without discoloration, strong corrosion resistance and pressure resistance
2: Tempered glass mask, high glass hardness, good light transmittance, good dustproof effect
3: Energy-saving high-brightness chip, brand LED high-brightness chip, long life, stable luminescence, low light decay, ultra-high lumen luminescence consistency
4: High-quality cold-proof wire, national standard multi-chip copper wire, better protection, better life, safe and reliable
Product Parameters
model | JT-WLD-6G3 |
Power (w) | 3W5W6W |
Number of LEDs | 356 |
LED color temperature (k) | 1800K-6500K RGB |
Initial luminous flux (m) | 270LM-540LM |
Luminous efficiency (lm/w) | 9OLM-100LM |
LED Chips | Cree OSRAM wafer optional |
LED Driver | Mean Well-Moso-Dongli available |
Input voltage(V) | DC24VAC220V |
Power Factor | 0.95 |
Color rendering index (Ra) | 80 |
Protection level | IP67 |
Lens Angle | 5'10-15°30°60° |
Lamp body material | The lamp body is made of 6063 aluminum alloy, the surface is anodized, and the lampshade is made of tempered glass |
Lamp Color | Silver grey and iron grey can be customized |
Installation | Screw bracket fixing |
Lamp size (mm) | 210*90*45mm |
Applicable places | Ancient building tiles brightening |
Net weight of lamp(kg) | |
Gross weight of lamp(kg) |
