Signal amplifier

Signal amplifier

Name:DMX512 signal amplifier

2 into 6 out: 2-way DMX512 direct output input / output

Optical isolation 8-way independent amplifier drive output signal amplification and shaping function

Extend the signal transmission distance to enhance the data bus access equipment

Number of ability to protect the lighting console DMX512 output interface

Fault site isolation, improve the safety of digital lighting control system operation reliability.

Technical parameters power supply: 100-240V 50-60HZ

Power cord: 3 * 0.75mm # European standard plug wide voltage input, adapt to different voltage input output: DMX512/1990 signal

Dimension:317mmx150mmx75mm

Weight:1.6kg
