Focus on high quality outdoor lighting fixtures
Performance Characteristics
1: The shell is made of high-quality aviation aluminum, which has a delicate feel and is tightly closed to prevent the infiltration of foreign debris. The polymer silicone seamless glue is dripped into the lamp body to make the inside of the lamp completely sealed in transparent silicone. It can work normally even if it is placed under water.
2: It uses high-quality imported high-lumen LED chips, which have higher brightness, more uniform color, more stable light, and longer life.
3: The installation base is made of high-strength aluminum alloy, which will never rust. It is firm, delicate, durable and easy to install.
4: The back uses a grid stripe air-enhancing design, and the convection design ensures that the heat is evacuated in time, allowing the heat dissipation of the lamp body to be faster.
Product Parameters
model | JT-XQD-48QH47 |
Power (w) | 12W |
Number of LEDs | 48 pieces |
LED color temperature (k) | 1800K-6500K RGB |
Initial luminous flux (m) | 1152LM |
Luminous efficiency (lm/w) | 22-26LM |
LED Chips | Cree OSRAM wafer optional |
LED Driver | External |
Input voltage(V) | DC24V |
Power Factor | 0.9 |
Color rendering index (Ra) | 80 |
Protection level | IP67 |
Lens Angle. | 120 degrees |
Lamp body material | The shell is made of high-quality aviation aluminum, which has a delicate feel and closes tightly to prevent the infiltration of foreign debris. |
Lamp Color | Iron grey, aluminum color, colors can also be customized |
Installation | Screw bracket fixing |
Lamp size (mm) | 30*30*1000mm |
Applicable places | Buildings, bridges, landmark lighting |
Net weight of lamp(kg) | |
Gross weight of lamp(kg) |
