Performance Characteristics
1: High-strength tensile profile structure, polymer silicone material overall potting waterproof and anti-static
2: The lamp shell is oxidized, the surface PC cover effectively prevents ultraviolet damage to the lamp
3: DC24V power supply to ensure effective signal transmission
4: Adopt SMDdg three-in-one full-color LED, the viewing angle is more than 120 degrees, and the color mixing effect is excellent
5: Constant current drive, built-in PWM grayscale control, RGB grayscale levels are up to 65536
Product Parameters
model | JT-SMG-48G |
Power (W) | 12W 15W |
Number of LEDs | 48 60 |
LED color temperature (k) | 1800K-6500K RGB RGBW |
Initial luminous flux (m) | 1152LM-1440LM |
Luminous efficiency (lm/w) | 24LM |
LED Chips | Cree OSRAM wafer optional |
LED Driver | External |
Input voltage(V) | DC24V |
Power Factor | 0.95 |
Color rendering index (Ra) | 80 |
Protection level | IP67 |
Lens Angle | 120 degrees |
Lamp body material | The shell is made of high-quality aviation aluminum, with a delicate feel and tight closure. |
Lamp Color | Iron grey, aluminum color, colors can also be customized |
Installation | Screw bracket fixing |
Lamp size (mm) | 40*65*1000mm |
Applicable places | Buildings, bridges, landmark lighting |
Net weight of lamp(kg) | |
Gross weight of lamp(kg) |
